SimoneCadence IC610的下载与安装（图文教程）（二）
的有关信息介绍如下：
本系列教程详细讲解了cadence ic610的下载与安装过程。
（一）必备条件 注意事项
（二）IC610的安装
(一)IC610的安装(在安装过程中，因为5张盘在同一个文件夹内，所以中间不会再问源文件的路径)
[redhat3@haidee CDROM1]$ cd /home/eda
[redhat3@haideeeda]$ ls
ic610 installscapemmsim61
[redhat3@haideeeda]$ pwd
/home/eda
[redhat3@haideeeda]$ cd /home/redhat3/ic610/
[redhat3@haideeic610]$ ls
Base_MMSIM61_lnx86_1of2.tar [集成电路版图设计].Base_IC610_lnx86_1of5.tar
Base_MMSIM61_lnx86_2of2.tar [集成电路版图设计].Base_IC610_lnx86_2of5.tar
IC610_lnx86.Base [集成电路版图设计].Base_IC610_lnx86_3of5.tar
IC610及MMSIM61的安装.pdf [集成电路版图设计].Base_IC610_lnx86_4of5.tar
IC610安装说明(图文版).pdf [集成电路版图设计].Base_IC610_lnx86_5of5.tar
[redhat3@haideeic610]$ cd IC610_lnx86.Base/
[redhat3@haideeIC610_lnx86.Base]$ LS
bash: LS:command not found
[redhat3@haideeIC610_lnx86.Base]$ ls
CDROM1 CDROM2CDROM3 CDROM4 CDROM5
[redhat3@haideeIC610_lnx86.Base]$ cd CDROM1
[redhat3@haideeCDROM1]$ ls
Base_IC610_lnx86.sdx IMAGES.DIRiscape README SETUP.SH
ic_index.sdx INSTALL.HTML MEDIA1.TXTREADMES sl2iswrap.zip
[redhat3@haideeCDROM1]$ ./SETUP.SH
Copyright1985-2006 by Cadence Design Systems Inc.
LICENSEDSOFTWARE - REVERSE ASSEMBLY, REVERSE COMPILATION AND
REVERSEENGINEERING PROHIBITED. The information contained in
thispackage is the proprietary property of Cadence Design Systems,
Inc., orits licensors, and may only be used in accordance with
theCadence Design Systems license agreement under which this
packageis provided.
RestrictedRights Notice to Government Users
Useduplication or disclosure by the Government is subject to
therestrictions as set forth in subparagraphs (c)(1)(ii) of the
Rights inTechnical Data and Computer Software clause at
DFARS252.227-7013. Unpublished - all rights reserved under the
copyrightlaws of the United States.
CadenceDesign Systems, Inc.
555 RiverOaks Parkway
San Jose,California 95134 USA
LocatedCDROM at /home/redhat3/ic610/IC610_lnx86.Base/CDROM1
Specifypath of install directory [OR type [RETURN] to exit]: /home/eda/ic610
Detecting InstallScape for lnx86...
CheckingInstallScape on media...
Could notdetect an InstallScape for lnx86 platform using the PATH environment variable
It is agood idea to have only one Installation of InstallScape
for lnx86platform. If an InstallScape installation exists
pleasehelp us find it.
Do youhave InstallScape for lnx86 platform installed somewhere [y/n]?n
You areon lnx86 platform
InstallScapeversion 03.40.p06
forplatform lnx86
isavailable on this CD.
Do youwant to install InstallScape for lnx86[y/n]:y
It isrecommended that you install InstallScape
outsidethe Cadence installation hierarchy
andinclude the ~iscape/bin in your PATH environment variable.
Type thepath to InstallScape installation directory [ (q to quit)]: /home/eda/installscape
InstallScapeinstallation directory: /home/eda/installscape
ExtractingInstallScape version 03.40.p06
forplatform lnx86 in /home/eda/installscape
Startingup InstallScape in GUI mode
DISPLAYenvironment variable is set to :0.0
If you donot see the InstallScape console
window orthe it seems to be hanging then kill this
process.
Set yourDISPLAY environment variable to a proper
value andmanually start InstallScape by typing:
/home/eda/installscape/iscape/bin/iscape.sh/home/redhat3/ic610/IC610_lnx86.Base/CDROM1:::/home/eda/ic610
InitializingInstallScape using JVM at /home/eda/installscape/iscape/runtime/LNX86/bin/java.This might take some time...
Xlib: connection to ":0.0" refused by server
Xlib: No protocol specified
（主要是说图形界面没有出现，这个时候你可能会怀疑操作系统版本的问题，但是别人用RHEL3&RHEL4都安装上了，其实这个再来查tar版本已经没有必要了，但是还是查了，仍然没有解决问题，最后在网上搜到解决方法了。
）
Exception in thread "main" java.lang.InternalError:Can't connect to X11 window server using ':0.0' as the value of the DISPLAYvariable.
atsun.awt.X11GraphicsEnvironment.initDisplay(Native Method)
atsun.awt.X11GraphicsEnvironment.
atjava.lang.Class.forName0(Native Method)
at java.lang.Class.forName(Class.java:141)
atjava.awt.GraphicsEnvironment.getLocalGraphicsEnvironment(GraphicsEnvironment.java:62)
atsun.awt.motif.MToolkit.
atjava.lang.Class.forName0(Native Method)
at java.lang.Class.forName(Class.java:141)
atjava.awt.Toolkit$2.run(Toolkit.java:748)
atjava.security.AccessController.doPrivileged(Native Method)
atjava.awt.Toolkit.getDefaultToolkit(Toolkit.java:739)
at com.khanpur.installer.gui.InstallerUI.main(InstallerUI.java:70)
[redhat3@haidee CDROM1]$
[redhat3@haidee CDROM1]$ cd /
[redhat3@haidee /]$ tar --version
tar (GNU tar) 1.13.25
Copyright © 2001 Free Software Foundation, Inc.
This program comes with NO WARRANTY, to the extent permittedby law.
You may redistribute it under the terms of the GNU GeneralPublic License;
see the file named COPYING for details.
Written by John Gilmore and Jay Fenlason.
[root@haidee /]# xhost +
access control disabled, clients can connect from anyhost
Initializing InstallScape using JVM at/home/eda/installscape/iscape/runtime/LNX86/bin/java. This might take sometime...
图示如下
接下图
